The Extron XTP T HWP 101 is a single-gang
Decora ® -style transmitter for sending HDMI with
embedded audio up to 330 feet (100 meters) over a
single shielded CATx cable. The one-gang form factor
provides maximum space efficiency for convenient
installation in wall mount, floor box, and furniture
mount applications. The transmitter is HDCP compliant
and supports computer video up to 1920x1200,
including 1080p/60 Deep Color and 2K resolutions. It
offers many of the integrator-friendly features that are
standard with XTP ® products, such as EDID Minder ®
and remote power capability. The single-gang
XTP T HWP 101 works with XTP Systems ® for signal
distribution and long-distance transmission in wall-
mount environments.
FEATURES
• Transmits HDMI with embedded audio up to
330 feet (100 m) over a shielded CATx cable
• Supports computer video up to 1920x1200,
including HDTV 1080p/60 Deep Color and 2K
• Extron XTP DTP 24 shielded twisted pair cable is
strongly recommended for optimal performance
• EDID Minder ® automatically manages EDID
communication between connected devices
• Key Minder ® continuously verifies HDCP compliance
for quick, reliable switching
• Remote power capability
• Compatible with all XTP integrated system products
