FEATURES
• Receives video with embedded audio, bidirectional RS-232 and IR, and
Ethernet up to 330 feet (100 meters) over a shielded CATx cable
• Scales HDMI, DVI, RGB, HD component video, and standard definition video
received from XTP devices, Single link HDMI
• Selectable output rates from 640x480 to 1920x1200, including 1080p/60 and 2K
• RJ45 Input with CATx shielded twisted pair cable
• Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for
optimal performance
• Bidirectional RS-232 and IR insertion for AV device control
• HDMI Output (HDCP compliant)
• EDID Minder and Key Minder
• Video supports HDCP, EDID, DDC Continuously, Data rate 6 Gbps
• RJ45 for Remote power capability
• Selectable HDMI audio pass-through
• Audio Bit rate 16, 20, 24 bit
• Digital Sampling 24 bit, 8 bit bits per color
• Audio Output combined with HDMI
• Analog Stereo supports Balance Impedance 100 Ohm, Uubalance Impedance 50 Ohm
• Receives video with embedded audio, bidirectional RS-232 and IR, and
Ethernet up to 330 feet (100 meters) over a shielded CATx cable
• Scales HDMI, DVI, RGB, HD component video, and standard definition video
received from XTP devices, Single link HDMI
• Selectable output rates from 640x480 to 1920x1200, including 1080p/60 and 2K
• RJ45 Input with CATx shielded twisted pair cable
• Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for
optimal performance
• Bidirectional RS-232 and IR insertion for AV device control
• HDMI Output (HDCP compliant)
• EDID Minder and Key Minder
• Video supports HDCP, EDID, DDC Continuously, Data rate 6 Gbps
• RJ45 for Remote power capability
• Selectable HDMI audio pass-through
• Audio Bit rate 16, 20, 24 bit
• Digital Sampling 24 bit, 8 bit bits per color
• Audio Output combined with HDMI
• Analog Stereo supports Balance Impedance 100 Ohm, Uubalance Impedance 50 Ohm
